Flat suction pads (oval) Series VTOF
Flat suction pads in NBR or Silicone.
Diameters from 4×2 to 90×30 mm with thread size M3, M5, G1/8, G1/4, both male and female.
Diameters from 4×2 to 90×30 mm with thread size M3, M5, G1/8, G1/4, both male and female.
Series VTOF flat oval suction pads consist of a nipple and rubber part.
The nipples are inserted directly into the rubber part.
Pads size 30×10 and larger are further equipped with a special clip in order to avoid unwanted rotation during operation.
The suction pads can also be ordered separately without nipples as spare parts.Applications:
The nipples are inserted directly into the rubber part.
Pads size 30×10 and larger are further equipped with a special clip in order to avoid unwanted rotation during operation.
The suction pads can also be ordered separately without nipples as spare parts.Applications:
- Handling of narrow workpieces with small undulated gripping surface such as plates, extruded profiles plastic components, etc.
- Handling of frame elements as for example doors, windows, etc.
- Silicone version for the handling of pieces at high temperatures.
