Flat suction pads (round) Series VTCF
Universal suction pads in NBR or Silicone.
Diameters from 3,5 to 95 mm with thread size M3, M5, G1/8, G1/4, both male and female.
Diameters from 3,5 to 95 mm with thread size M3, M5, G1/8, G1/4, both male and female.
Series VTCF flat suction pads consist of a nipple and rubber part which are delivered separately.
In fact, both components can be ordered separately as spare parts.
From diameter 60 mm and up a mounting plate is vulcanised into the rubber part to which the nipple should be mounted.
In fact, both components can be ordered separately as spare parts.
From diameter 60 mm and up a mounting plate is vulcanised into the rubber part to which the nipple should be mounted.
These suction pads are generally used for handling of objects with smooth or slightly curved surfaces such as sheets of different materials, extruded profiles, cardboard boxes, plastic components, wood panels etc.
Applications:
- Handling of flat parts with smooth or slight rough surfaces.
- Silicone version for the handling of parts at high temperatures.
