Activated carbon filters Series MD
Ports with interchangeable cartridges: threaded (1/8, 1/4, 3/8) or integrated with super-rapid fitting for tube with Ø 6, 8 and 10 mm
Modular assembly
Bowl with technopolymer cover and bayonet-type mounting
Modular assembly
Bowl with technopolymer cover and bayonet-type mounting
Within a battery of filters the activated carbon version is placed at the end because it requires a pre-filtering like the coalescing filter.
Given the characteristic of this filter, it is recommended to replace the filter element at least every 6 months or 1000 working hours.The operating principle is based on the adsorption characteristic of the filtering element which is composed of extremely porous fibers placed on different layers.
These fibers create a cross-linked and are thus able to adsorb wet parts and contaminants remaining in the passing air, for example oil vapours/smokes, as well as odours generated from these contaminants.
Given the characteristic of this filter, it is recommended to replace the filter element at least every 6 months or 1000 working hours.The operating principle is based on the adsorption characteristic of the filtering element which is composed of extremely porous fibers placed on different layers.
These fibers create a cross-linked and are thus able to adsorb wet parts and contaminants remaining in the passing air, for example oil vapours/smokes, as well as odours generated from these contaminants.
