Pneumatic pilot operated pressure regulators Series MX
Ports: G3/8, G1/2, G3/4
Modular – Available with built-in pressure gauges or ports for gauges
Modular – Available with built-in pressure gauges or ports for gauges
The availability of constant values of the secondary pressure ensures performance optimization and energy saving.
All regulators are equipped with an integrated locking system and built-in pressure gauges for a more compact product.The Series MX has been realized to offer a multi-sector solution that guarantees saving in terms of installation time, space and costs.
All regulators are equipped with an integrated locking system and built-in pressure gauges for a more compact product.The Series MX has been realized to offer a multi-sector solution that guarantees saving in terms of installation time, space and costs.
