Pressure microregulators Series T
Ports G1/8 and G1/4
Series T pressure regulators are available with G1/8 and G1/4 brass connections.
A self-relieving piston has been incorporated into the design to allow decreasing adjustments.
Non-relieving versions are also available.
A self-relieving piston has been incorporated into the design to allow decreasing adjustments.
Non-relieving versions are also available.
All models are equipped with a by-pass valve which is useful when a regulator should be inserted between the valve and cylinder (or capacity) without any negative influence on the exhaust.
