Filters, coalescing filters and activated carbon filters Series N
Ports: G1/8, G1/4
Series N filters are available with G1/8 and G1/4 gas ports.
The models are available with 3 different filtering elements: 25, 5, 0,01µm and actived carbon.The version with semi-automatic manual drain is equipped with a transparent bowl that makes the monitoring of the condensate level very easy.The version with metal bowl is particularly suitable for applications subject to impacts or in the presence of aggressive agents that could damage the PA12 bowl.
The models are available with 3 different filtering elements: 25, 5, 0,01µm and actived carbon.The version with semi-automatic manual drain is equipped with a transparent bowl that makes the monitoring of the condensate level very easy.The version with metal bowl is particularly suitable for applications subject to impacts or in the presence of aggressive agents that could damage the PA12 bowl.
