Coalescing filters Series MX
MX2 ports: G3/8, G1/2, G3/4 – MX3 ports: G3/4, G1
Modular
Bowl with technopolymer cover and bayonet-type mounting
Modular
Bowl with technopolymer cover and bayonet-type mounting
The Series MX air treatment components are characterized by a modern, linear and compact design, offering high performances.
The perfect integration between metal alloys and technopolymers has allowed the realization of a reliable product, light and strong at the same time.
Thanks to a new concept of modularity, moreover, the mounting of components has become easier.The Series MX has been realized to offer a multi-sector solution that guarantees saving in terms of installation time, space and costs.
The perfect integration between metal alloys and technopolymers has allowed the realization of a reliable product, light and strong at the same time.
Thanks to a new concept of modularity, moreover, the mounting of components has become easier.The Series MX has been realized to offer a multi-sector solution that guarantees saving in terms of installation time, space and costs.
