Bellows suction pads (oval) for Packaging – 1,5 folds Series VPOL
Suction pads in Elastodur ED-65 or Silicone.
Dimensions from 60×20 to 100×40 mm with thread size G1/8 and G1/4, both male and female.
Dimensions from 60×20 to 100×40 mm with thread size G1/8 and G1/4, both male and female.
Series VPOL suction pads consist of a nipple and rubber part which are delivered assembled.
Both components can be ordered separately as spare parts.
Both components can be ordered separately as spare parts.
These suction pads are very suitable for the handling of packagings like rigid cardboard boxes or trays.
Common applications are:
- Palletising and de-palletising processes.
- Heavy-duty applications in terms of hold and wear.
- Loading from the top and from the side in cartoning machines.
General Data
| Description | Robust hard-wearing suction pads consisting of suction pad VPOL and connection nipple. |
| Construction | Nipples and suction pads are supplied already assembled. Diameters of 60 mm and more: nipple screwed into supporting plate vulcanised to the pad. |
| Maintenance | It is possible to replace the soft element. |
| Working temperature | ELASTODUR version: -40°C ÷ +100°C (for short time <30 sec.); -25°C ÷ +80°C (long-term) SILICONE version: -40°C ÷ +220°C (for short time <30 sec.); -30°C ÷ +180°C (long-term) |
Coding Example
| VP | O | L | – | 0350-150 | E | – | G1/8 | M |
| VP | SERIES VP = suction pad |
| O | SHAPE O = oval |
| L | VERSION L = 1,5 folds |
| 0350-150 | DIAMETERS 0350-150 = 35,0 x 15,0 mm 0600-200 = 60,0 x 20,0 mm 0600-250 = 60,0 x 25,0 mm 0800-350 = 80,0 x 35,0 mm 1000-400 = 100,0 x 40,0 mm |
| E | MATERIALS E = elastodur (0600-1000) S = silicone (0350-0600-0800) |
| G1/8 | THREAD SIZE 1/8 = G1/8 1/4 = G1/4 |
| M | THREAD M = male F = female |
