Valves and solenoid valves Series D VB version
2×3/2; 5/2; 5/3-way
Manifold assembly
Size 10,5 – 16 – 25 mm
Manifold assembly
Size 10,5 – 16 – 25 mm
Camozzi has developed a new series of valves for applications with limited installation space where it is necessary to have the control elements as close to the actuator as possible.
Thanks to the extreme robust aluminium body, the Series D valves guarantee maximum reliability even under difficult operating conditions.
Thanks to the extreme robust aluminium body, the Series D valves guarantee maximum reliability even under difficult operating conditions.
