Valves and solenoid valves Series D VA version
3/2; 2×3/2; 5/2; 5/3-way
With outlets on the body – For individual or manifold assembly
Size 10,5 – 16 – 25 mm
With outlets on the body – For individual or manifold assembly
Size 10,5 – 16 – 25 mm
Camozzi has developed a new series of valves for applications with limited installation space where it is necessary to have the control elements as close to the actuator as possible.
Valves with threads on the body can be used individually or assembled on manifold. The sub-base version allows a better cleaning of the application.
Thanks to the extreme robust aluminium body, the Series D valves guarantee maximum reliability even under difficult operating conditions.
Valves with threads on the body can be used individually or assembled on manifold. The sub-base version allows a better cleaning of the application.
Thanks to the extreme robust aluminium body, the Series D valves guarantee maximum reliability even under difficult operating conditions.
