Sub-D adaptor module 25 pin Mod. CXA-25P
It is an Expansion module of the serial subnet that can be made through a CX3 multi-serial module and can be connected to all valve islands with Sub-D 25 pin connection. It can manage up to a maximum of 24 Output. It has its own M12 A 4 pin male connection for the supply of the valves connected, distinguishing both logic supply and power supply and two M12 D 4 pin female connections for the Bus-IN and Bus-OUT of the subnet. The subnet can have a maximum length of maximum 100 metres. The power of a single Output is 3 W to 24 V DC. Thanks to the PWM technique it is possible to set a power reduction to only maintain operation.
Led 1 = Yellow LNK1
Led 2 = Yellow LNK2
Led 3 = Green PWR, supply present and OK
