Lubricators Series MD
Ports with interchangeable cartridges: threaded (1/8, 1/4, 3/8) or integrated with super-rapid fitting for tube with Ø 6, 8 and 10 mm
Modular assembly
Bowl with technopolymer cover and bayonet-type mounting
Modular assembly
Bowl with technopolymer cover and bayonet-type mounting
The lubricator allows the nebulization of lubricating oil which is necessary to the functioning of components in specific conditions of use.
By means of a regulation screw the amount of oil can be properly adjusted in order to avoid unnecessary overdoses.
