Lockable isolation 3/2-way valves Series MD
Ports with interchangeable cartridges: threaded (1/8, 1/4, 3/8) or integrated with super-rapid fitting for tube with Ø 6, 8 and 10 mm
Modular
Manual, electro-pneumatic, servo-pilot and pneumatic control
Modular
Manual, electro-pneumatic, servo-pilot and pneumatic control
The Series MD offers multi-sector solutions that ensure saving in terms of installation time, space and costs.
Series MD lockable isolation valves allow the inlet and exhaust of compressed air from the plant and can meet several application requirements.
Series MD lockable isolation valves allow the inlet and exhaust of compressed air from the plant and can meet several application requirements.
The electric version can be equipped with different options of manual override (Push & Turn, Push-in, retaining lever).
Moreover, a version without override is also available.
The manually operated valve can be locked thanks to the use of padlocks.
