Flow control valves Series CLFB, CLFC
Unidirectional and bidirectional flow regulators with in technopolymer (G1/8, G1/4, G3/8)
Ports: M5, G1/8, G1/4, G3/8
These unidirectional and bidirectional flow control valves are designed to be directly mounted on valves or cylinders with only a small footprint.
The wide range of swivel fittings allows to complete the flow control valve with the most suitable configuration based on the type of tube used.
All models are supplied with a swivel fitting.
General Data
| Type of regulator | Needle type |
| Valve group | Unidirectional and bidirectional controller |
| Materials | Body, regulation screw: stainless steel (M5), brass (G1/8 – G1/4 – G3/8) GRIPfit cartridge = technopolymer and stainless steel Banjo: brass (M5), technopolymer (G1/8 – G1/4 – G3/8) Controller = technopolymer – seals = NBR |
| Mounting | By male thread |
| Ports | M5 – G1/8 – G1/4 – G3/8 |
| Installation | In any position |
| Operating temperature | 0°C ÷ 60°C (with dry air -20°C) |
| Operating pressure | 1 ÷ 10 bar |
| Nominal pressure | 6 bar |
| Nominal flow | See graph |
| Nominal diameter Ø [mm] | M5 = 1,5 mm – G1/8 = 2 mm – G1/4 = 4 mm – G3/8 = 7 mm |
| Fluid | Filtered air. If lubricated air is used, it is recommended to use ISOVG32 oil. Once applied the lubrication should never be interrupted. |
Coding Example
| CL | FB | – | 1/8 | – | 6 | – | C | – | G |
| CL | SERIES CL = Compact Line |
| FB | FUNCTION FB = Flow regulator, threaded / tube / manual FC = Flow regulator, threaded / tube / screwdriver |
| 1/8 | PORTS M5 = M5 1/8 = G1/8 1/4 = G1/4 3/8 = G3/8 |
| 6 | TUBE 4 = tube Ø 4 6 = tube Ø 6 8 = tube Ø 8 10 = tube Ø 10 12 = tube Ø 12 |
| C | VERSION C = Unidirectional on cylinder V = Unidirectional on valve B = Bidirectional |
| G | G = Gripfit |
