Brass universal nose fittings Series 1000
Nose fittings for plastic, copper and brass tubes: Ø 4, 6, 8, 10, 12 mm
Fittings threads: BSP (G1/8, G1/4), BSPT (R1/8, R1/4, R3/8, R1/2)
Fittings threads: BSP (G1/8, G1/4), BSPT (R1/8, R1/4, R3/8, R1/2)
Series 1000 nose fittings are used with plastic tubes as well as with copper, brass, steel and aluminium tubes.
These fittings, which are suitable for several applications, can be used within pneumatic, oil-pressure and low-pressure hydraulic circuits.
These fittings, which are suitable for several applications, can be used within pneumatic, oil-pressure and low-pressure hydraulic circuits.
The fittings seats, noses and nuts comply with the DIN 3870-3861 standards.
