Valves and solenoid valves Series 3
2×3/2, 3/2, 5/2 and 5/3-way CC CO CP
Ports: G1/8 and G1/4
Ports: G1/8 and G1/4
Series 3 solenoid valves with G1/8 and G1/4 ports have been designed in the 3/2, 2 x 3/2, 5/2, 5/3 versions and with the following two devices of actuation:
- Electropneumatically actuated with mechanical spring return
- Electropneumatically actuated with external and internal air pressure supply
Series 3 valves are equipped with a manual override which allows a stable
operation and they can use Series U or G solenoids (22×22).
Pneumatically actuated valves 3/2 NC become NO when the supply is on connection 3.
