Shock absorbers Series SA
7 different sizes
Threads: M8x1 – M10x1 – M12x1 – M14x1,5 – M20x1,5 – M25x1,5 – M27x1,5
Threads: M8x1 – M10x1 – M12x1 – M14x1,5 – M20x1,5 – M25x1,5 – M27x1,5
Series SA shock absorbers exist in 7 different sizes and are used to provide impact and noise absorbtion when stopping objects in motion.
Series SA is of a self compensating type which makes it suitable for different applications such as low load/high speed or high load/low speed applications without requiring any additional adjustments on the shock absorber.
Series SA is designed so it can be used with or without a stop collar.By using shock absorber Series SA, following advantages would be provided.
Series SA is of a self compensating type which makes it suitable for different applications such as low load/high speed or high load/low speed applications without requiring any additional adjustments on the shock absorber.
Series SA is designed so it can be used with or without a stop collar.By using shock absorber Series SA, following advantages would be provided.
- Increased production rate;
- Reduced maintenance costs;
- Reduce noise and vibration;
- Extended life time of the machine.
General Data
| Model | SA-0806 SA-1007 SA-1210 SA-1412 SA-2015 SA-2525 SA-2725 |
| Type of construction | Hydraulic shock absorber, self compensating |
| Materials | Body: steel, black coated Piston rod: carbon steel chrome plated Piston: carbon steel Sealings: NBR |
| Threaded body | M8x1 – M10x1 – M12x1 – M14x1,5 – M20x1,5 – M25x 1,5 – M27x 1,5 |
| Absorption stroke (mm) | 6; 7; 10; 12; 15; 25; 25 |
| Max. Energy absorption per cycle, Et [Nm] | 3; 6; 12; 20; 59; 80; 147. |
| Max. Energy absorption per hour, ETc, [Nm] | 7000; 12400; 22500; 33000; 38000; 60000; 72000. |
| Max. effective mass Me [kg] | 6; 12; 22; 40; 120; 180; 270 |
| Max number of cycles per minute | 80; 70; 40; 70; 45; 20; 10 |
| Impact speed, (m/s) min. – max. | 0,3 – 2,5; 0,3 – 3,5; 0,3 – 4,0; 0,3 – 5,0; 0,3 – 5,0; 0,3 – 5,0; 0,3 – 5,0. |
| Weight (g) | 15; 25; 32; 65; 150; 295; 360 |
| Working temperature | -10°C ÷ +80°C |
Coding Example
| SA | – | 2015 |
| SA | SERIES |
| 2015 | SIZE/STROKE 0806 = Size M8x1 / Stroke 6 mm 1007 = Size M10x1 / Stroke 7 mm 1210 = Size M12x1 / Stroke 10 mm 1412 = Size M14x1,5 / Stroke 12 mm 2015 = Size M20x1,5 / Stroke 15 mm 2525 = Size M25x1,5 / Stroke 25 mm 2725 = Size M27x1,5 / Stroke 25 mm |
| VERSION = Standard, with cap W = Without cap (on request) |
