Nickel-Plated Brass Pipe Fittings Series 2000 – Inch
Thread Type: 10-32 UNF;
NPTF (1/8″, 1/4″, 3/8″, 1/2″);
Metric (M5);
BSP (G1/8, G1/4, G3/8, G1/2, G3/4, G1);
BSPT (R1/8, R1/4, R3/8, R1/2, R3/4).
NPTF (1/8″, 1/4″, 3/8″, 1/2″);
Metric (M5);
BSP (G1/8, G1/4, G3/8, G1/2, G3/4, G1);
BSPT (R1/8, R1/4, R3/8, R1/2, R3/4).
When involved in factory maintenance or plant installation it is often difficult to be absolutely certain which size of fittings will be required.
Pipe fittings provide a cost effective solution to this problem.
The full range includes straight, L-shaped, T-shaped and cross piece male or female couplings and are available in a variety of thread sizes up to 3/4”.
The addition of the Camozzi Sprint® seal to twelve different models of pipe fittings eliminates the need to use liquid sealants or tape and save a considerable amount of time during installation.
The Sprint® fitting can be connected and disconnected several times.
Pipe fittings provide a cost effective solution to this problem.
The full range includes straight, L-shaped, T-shaped and cross piece male or female couplings and are available in a variety of thread sizes up to 3/4”.
The addition of the Camozzi Sprint® seal to twelve different models of pipe fittings eliminates the need to use liquid sealants or tape and save a considerable amount of time during installation.
The Sprint® fitting can be connected and disconnected several times.
Material: brass OT58 UNI 5705 (nickel-plated).
- T. min. – 40°C (- 40°F)
- T. max. + 120°C (250°F)
