Mechanically operated minivalves Series 2
3/2-way
Ports M5, cartridge Ø4
Ports M5, cartridge Ø4
Series 2 mechanically operated miniature valves, 3/2-way normally closed, are available with M5 threaded ports or with an integrated super-rapid fitting for Ø4mm tubes.
The devices are actuated by a plunger, roller/lever or a unidirectional lever.
The devices are actuated by a plunger, roller/lever or a unidirectional lever.
