Compact ejectors Series VEM
Miniaturized vacuum generators with integrated valves and monitoring system. Possibility to command suction and blow-off individually without using external valves.
One of the most important features of Series VEM compact ejector is the extreme compactness.
This compactness and low weight makes them suitable for “dynamic” applications such as robots, when assembled directly on the part in motion (gripper head etc.)
This compactness and low weight makes them suitable for “dynamic” applications such as robots, when assembled directly on the part in motion (gripper head etc.)
The Compact ejector Series VEM have integrated suction-and blow off individually without using external valves.
With these it is therefore possible to command suction and blow-off individually without using external valves.
The compact ejectors Series VEM are often used in completely automatic handling systems.
