Basic ejectors Series VEBL
Basic ejectors in technopolymer without moving parts, based on the Venturi principle.
Different sizes available, with internal nozzle from 0,5 to 2,5 mm and with suction rate from 8 to 207 l/min.
Different sizes available, with internal nozzle from 0,5 to 2,5 mm and with suction rate from 8 to 207 l/min.
Series VEBL basic ejectors are universal ejectors made in technopolymer suitable for several industrial applications such as:
- Industrial robotics in most sectors
- Wood industry
- Packaging industry
- Food industry
