Basic ejectors Series VEB
Basic ejectors with no moving parts, based on the Venturi principle.
Version “L” for porosive workpieces.
Version “H” for high vacuum value.
Version “L” for porosive workpieces.
Version “H” for high vacuum value.
Series VEB basic ejectors are universal ejectors suitable for several industrial applications.
They are available in two versions:
- Version “L” for porosive workpieces
- Version “H” for high vacuum value (85%)
Applications:
- Industrial robotics in most sectors.
- Wood industry.
- Packaging industry.
- Food industry.
General Data
| Description | Body in anodized Aluminium Internal nozzle in brass Silencer in technopolymer |
Coding Example
| VEB | – | 05 | H |
| VEB | SERIES VEB = vacuum ejector |
| 05 | NOZZLE DIAMETER 05 = 0,5 mm 07 = 0,7 mm 10 = 1 mm 15 = 1,5 mm 20 = 2 mm 25 = 2,5 mm 30 = 3 mm |
| H | SUCTION TYPE H = high vacuum L = high suction rate |
