Assembled FRL Series MD
Ports with interchangeable cartridges: threaded (1/8, 1/4, 3/8) or integrated with super-rapid fitting for tube with Ø 6, 8 and 10 mm
Modular assembly
Modular assembly
The Series MD offers multi-sector solutions that ensure saving in terms of installation time, space and costs.
The various functions can be connected by means of intermediate junctioning cartridges.
The regulator and the valves can be adjusted so as to have the regulation devices or the actuation in front or lower position.
There are different types of wall mounting available.Thanks to the solution adopted for the pneumatic connection, it is possible to equip the same element with interchangeable cartridges that can either be threaded, or with an integrated super-rapid fitting, both types available in different sizes. Intermediate cartridges can be also integrated to join multiple functions or with derivation to draw air.
The various functions can be connected by means of intermediate junctioning cartridges.
The regulator and the valves can be adjusted so as to have the regulation devices or the actuation in front or lower position.
There are different types of wall mounting available.Thanks to the solution adopted for the pneumatic connection, it is possible to equip the same element with interchangeable cartridges that can either be threaded, or with an integrated super-rapid fitting, both types available in different sizes. Intermediate cartridges can be also integrated to join multiple functions or with derivation to draw air.
