Inline vacuum filters Series FVD
For use in vacuum systems with minor to medium levels of dirt.
Direct mounting on the suction pad.
Direct mounting on the suction pad.
These filters can be mounted directly on the suction pad.
The filter element can be easily substituted and its conditions can be checked thanks to its transparent wrapping.
The filter element can be easily substituted and its conditions can be checked thanks to its transparent wrapping.
General Data
| Description | Inline filter |
| Materials | Body in technopolymer Cloth filter |
Coding Example
| FVD | – | 4/2 | – | 50 |
| FVD | SERIES FVD = inline filter |
| 4/2 | CONNECTIONS 4/2 = tube 4 6/4 = tube 6 8/6 = tube 8 |
| 50 | FILTER ELEMENT 50 = 50 µm |
