Frequency Inverter – CFW501 Series
The CFW501 inverter line has been developed with dedicated features for HVAC-R applications. With compact size and special functions for this market, it is the ideal solution for pumps and fans, and can be used in shopping centers, hospitals, hotels, airports or similar.
RELATED PRODUCTS
AFW11M – Cabinet-built Modular Frequency Inverter
The AFW11M G2, commonly referred to as “modular drive”, was developed for mounting on a modular structure, and it is available to supply high output currents with the choice of specification according to the application needs.
They are supplied in the versions with air-cooled heatsink (AFW11M) or water-cooled heatsink (AFW11W), using the new generation of modular inverters CFW11M G2 / CFW11W, in the voltages of 380 to 690 V, with input rectifier in six pulses, twelve pulses or regenerative.
MVW01 – Medium Voltage Drive
The MVW01 G4 (IoT Ready), WEG's medium-voltage frequency inverter, was designed to meet the demands of electric motor control in applications with power up to 55,520 HP and voltages up to 6.9 kV. Featuring cutting-edge technology with high-voltage IGBTs, it uses NPC and HNPC topologies, along with flexible air and water cooling systems. It ensures high operational safety with protections against electrical arcs and an optional arc-resistant enclosure.
Equipped with a 10-inch touchscreen HMI interface, the MVW01 G4 offers seamless interaction for programming and real-time monitoring. Connectivity with major communication protocols, including EtherNet/IP, Profinet, Modbus-TCP, and MQTT, is supported. Additionally, it integrates directly and securely with the WEG Motion Fleet Management platform, providing intelligent asset management and predictive maintenance.
Rigorously tested in WEG laboratories and compliant with safety and efficiency standards, the MVW01 G4 ensures high reliability for critical high-power applications. A symbol of efficiency, robustness, and safety, it meets the needs of various industries, promoting energy savings, reducing operational costs, and reinforcing WEG’s commitment to sustainability.
MW500 G2 Decentralized Drive
The MW500 G2 is a high-performance variable speed drive for controlling three-phase induction motors with dedicated functions and high degree of protection IP66/NEMA4X that allow their use in applications requiring a high level of precision and robustness. In addition, the MW500 has excellent flexibility because it can be installed directly on the wall or mounted on the motor, reducing costs of wiring and panels.
Regenerative Power Supply AFE200
The AFE200 range has power ratings of 22kW to 1.65MW for three-phase power supplies of 400VAC to 690VAC. Ease of use and intuitive programming make it possible for users of any level to exploit the high-level performance of Active Front End technology for a broad range of applications where there is a need for real energy saving.
Variable speed drive ADV200-SP
Solar-powered water pumping is based on PV technology that converts sunlight into electricity to pump water.
The PV panels are connected to an ADV200 SP drive, which converts the electrical energy supplied by the PV panel into mechanical energy, and this in turn is converted into hydraulic energy by the pump.
Synergies between the ADV200 SP Industrial Drives technology and the company’s Solar and Pump application know-how have allowed WEG to develop a special SW with lift controller and special function to optimize the operation of solar pump systems.
In addition the ADV200 SP is able to manage pumping systems powered by different sources: solar PV panels alone (off-grid), or both PV panels and grid supply (dual supply systems).
