Foot operated pedal Electrical and pneumatic Series 3 and Series 2
Series 3: G1/4, 5/2-way – NC / NO contacts
Series 2: M5; 4/2 tube; 3/2-way NC
Series 2: M5; 4/2 tube; 3/2-way NC
The pedals can be supplied in either a pneumatic or electrical foot operated version.
The pneumatic type is available with a 5/2 valve and G1/4 front ports, which allow the fittings and silencers to be assembled conveniently on the front face.
A 3/2 operation can be obtained by closing an outlet port.
The electrical type is available with a single-pole changeover contact microswitch and a front wire outlet (PG9).
The pneumatic type is available with a 5/2 valve and G1/4 front ports, which allow the fittings and silencers to be assembled conveniently on the front face.
A 3/2 operation can be obtained by closing an outlet port.
The electrical type is available with a single-pole changeover contact microswitch and a front wire outlet (PG9).
The pedal can be operated as bistable or monostable, by switching the selector placed under the small red protection flap, as shown in the drawing.
General Data
| Valve group | 5/2, 3/2 NC way/pos. |
| Materials | Series 3: alluminium body – stainless steel spool – NBR seals – plastic casing Series 2: alluminium body – OT58 poppet – NBR seals. |
| Ports | Series 3: G1/4 gas Series 2: M5; tube 4/2. |
| Environmental temperature | 0°C ÷ 50 °C (with dry air at – 10°C) |
| Medium temperature | 0°C ÷ 50 °C |
| Construction | Spool-type |
| Cable entry | By means of wire PG9 |
| Protection class | IP20 |
| Fluid | Filtered air, without lubrication. If lubricated air is used, it is recommended to use ISO VG32 oil. Once applied the lubrication should never be interrupted. |
