Electromechanical cylinders Series 6E
Sizes 32, 40, 50, 63, 80, 100
The Series 6E cylinders are mechanical linear actuators with rod, in which the rotary movement, generated by a motor, is converted into a linear movement by means of a recirculating ball screw.
Available in 6 sizes, the Series 6E has dimensions based on the ISO 15552 standard and it is therefore possible to use the mounting accessories of the pneumatic cylinders.The cylinders are equipped with a magnet that makes it possible to use external magnetic proximity switches (Series CST and CSH), allowing operations like homing or extra-stroke readings to be performed.
The Series 6E is equipped with specific interface kits, which make it possible to connect the motor, both in line and parallel.
High precision and easy mounting make the Series 6E the ideal solution for different applications, especially for multi-position systems.
Available in 6 sizes, the Series 6E has dimensions based on the ISO 15552 standard and it is therefore possible to use the mounting accessories of the pneumatic cylinders.The cylinders are equipped with a magnet that makes it possible to use external magnetic proximity switches (Series CST and CSH), allowing operations like homing or extra-stroke readings to be performed.
The Series 6E is equipped with specific interface kits, which make it possible to connect the motor, both in line and parallel.
High precision and easy mounting make the Series 6E the ideal solution for different applications, especially for multi-position systems.
