Cylinders Series 42
Single and double-acting, magnetic, cushioned
Ø 32, 40, 50, 63 mm
Ø 32, 40, 50, 63 mm
Series 42 cylinders have been designed without tie rods to assure an extremely clean design.
Stainless steel has been used for the tube and the rod, while the end cover is made in anodized Aluminium. These cylinders are normally equipped with adjustable end-stroke cushioning and with a mechanical cushioning in order to make the impact of the piston less noisy as it reaches the end of the stroke.
Stainless steel has been used for the tube and the rod, while the end cover is made in anodized Aluminium. These cylinders are normally equipped with adjustable end-stroke cushioning and with a mechanical cushioning in order to make the impact of the piston less noisy as it reaches the end of the stroke.
General Data
| Type of construction | Compact – flanged |
| Operation | Single-acting or double-acting |
| Materials | End-blocks = AL Tube = stainless steel AISI 304 Rod = stainless steel AISI 420B Other parts (see coding) |
| Type of mounting | Front flange, rear flange, feet, front and rear trunnion, threaded pins |
| Strokes min – max | 10 – 1000 mm |
| Operating temperature | 0 ÷ 80°C (with dry air -20°C) |
| Operating pressure | 1 ÷ 10 bar (double-acting); 2 ÷ 10 bar (single-acting) |
| Speed | 10 ÷ 1000 mm/sec (NO LOAD) |
| Fluid | Clean air, without lubrication. If lubricated air is used, it is recommended to use oil ISOVG32. Once applied the lubrication should never be interrupted. |
Coding Example
| 42 | M | 2 | N | 050 | A | 0200 |
| 42 | SERIES | |
| M | VERSION M= standard magnetic |
|
| 2 | OPERATION 1 = single-acting, cushions (front spring) 2 = double-acting, front and rear cushions 3 = double-acting, no cushion 4 = double-acting, rear cushions 5 = double-acting, front cushion 6 = double-acting, through-rod, front and rear cushions 7 = single-acting, through-rod, cushions |
PNEUMATIC SYMBOLS CS12 CD09 CD08 CD10 CD11 CD13 CS13 |
| N | MATERIALS N = stainless steel AISI 420B rod – stainless steel AISI 304 tube – NBR seals |
|
| 050 | BORE 032 = 32 mm 040 = 40 mm 050 = 50 mm 063 = 63 mm |
|
| A | TYPE OF DESIGN A = standard with nose nut Mod. V and piston rod lock nut Mod. U |
|
| 0200 | STROKE (see the table) |
