VEGAPOINT 21
Compact capacitive limit switch
For the detection of water-based liquids
Application area
From DK > 1.5, from thread ½”, universal connection G1″ for hygiene adapter, M12, valve plug, transistor output, IO-Link, wireless operation, Ex and hygiene approvals
VEGAPOINT 21 is a low-cost limit switch for the detection of water-based liquids. The optional universal connection for hygiene adapters ensures reduced installation effort and leaner stock keeping and perfectly meets the requirements for hygienic processes in the food, beverage and pharmaceutical industries. It can be used without adjustment in the application. With IO-Link, it offers continuous digital data transmission.
Your benefit
- Coloured 360° status display, adjustable
- Easy integration into control systems through IO-Link communication
- Low-cost limit switch with smallest installation dimensions
RELATED PRODUCTS
VEGACAL 63
Capacitive rod probe for continuous level measurement
Rod probe, fully PE or PTFE insulated
Application area
For measurement in conductive and non-conductive liquids. A full/empty adjustment is necessary for setup.
The VEGACAL 63 level sensor can be used universally for the measurement of conductive and non-conductive liquids. The rod electrode is fully insulated and the proven mechanical construction offers high functional safety.
Your benefit
- Savings through simple mounting and setup
- Long lifetime and low maintenance requirement through robust mechanical construction
- Maximum utilization of the vessel because measurement over the complete probe length
VEGACAL 64
Capacitive rod probe for continuous level measurement of adhesive products
Rod probe, fully FEP insulated
Application area
For conductive and non-conductive liquids. The rod measuring probe is fully insulated and especially suitable for viscous and adhesive products. A full/empty adjustment is necessary for setup.
The VEGACAL 64 is a level sensor for conductive and non-conductive liquids. The rod electrode is fully insulated and is particularly suitable for viscous and adhesive products.
Your benefit
- Reduced number of cleaning cycles through measurement insensitive to buildup
- Long lifetime and low maintenance requirement through robust mechanical construction
- Maximum utilization of the vessel because measurement over the complete probe length
VEGAFLEX 86
TDR sensor for continuous level and interface measurement of liquids
For the most extreme process conditions
Application area
Cable, rod or coaxial sensor. Its robust, mechanical design and the second process seal, the Second Line of Defense, protect the sensor for demanding measurement tasks. Process temperature: -196 ... 450° C; process pressure: -1 … 400 bar
The VEGAFLEX 86 level sensor measures maintenance-free all liquids under extreme pressure and temperature conditions. Even in applications with buildup, foam generation and condensation, the sensor delivers precise and reliable measured values. In saturated steam applications, a special reference probe ensures a density-independent measurement. The VEGAFLEX 86 offers an economical level and interface measurement for your application.
Your benefit
- The guided adjustment enables a simple, time-saving and reliable setup
- Shortenable probes offer a simple standardisation and highest flexibility in the planning
- Comprehensive diagnostic possibilities ensure a maintenance-free operation and hence a high plant availability
VEGAPULS 31
Compact radar sensor for continuous level measurement
For standard measuring tasks, plastic housing IP66/IP67, type 4X, display
Application area
4 ... 20 mA/HART output, measuring range up to 20 m, accuracy ±2 mm, Ex approval optional, on-site display and 3-button operation
VEGAPULS 31 is the ideal sensor for non-contact level measurement of liquids and bulk solids in simple applications. It is particularly suitable for use in water treatment, storage tanks with acids, lyes and additives in all industrial areas, or for measuring levels in plastic tanks from the outside through the tank wall. In bulk solids the sensors are used in small bulk solids silos or open containers.
Your benefit
- Exact measurement results independent of medium properties and process conditions
- On-site display for easy level control
- Maintenance-free operation due to non-contact 80 GHz radar technology
VEGAPULS Air 23
Autarkic, continuous level measurement in plastic vessels
Autarkic sensor with measured value transmission by radio technology
Application area
NB-IoT/CAT-M1, LoRa, measuring range up to 3m, accuracy +/-5mm
VEGAPULS Air 23 is the ideal sensor for level measurement in IBCs and plastic vessels. The instrument measures through the closed vessel ceiling and is suitable for nearly all liquids and bulk solids. VEGAPULS Air 23 is quickly mounted by simple and reliable adhesive, ceiling or tension belt mounting. Since no additional power supply is necessary, the autarkic sensor offers a particularly economical solution. The sensor housing with high protection rating IP69 enables maintenance-free continuous operation even outdoors or when cleaning the vessel.
Your benefit
- Exact measuring results independent of medium, process and ambient conditions
- Maintenance-free operation due to non-contact 80 GHz radar technology
- Easy installation thanks to autarkic voltage supply and radio technology
