VEGACAP 27
Adjustment-free, capacitive rod probe for level detection of adhesive products
Rod probe, fully PTFE or PFA insulated
Application area
For liquids, also in non-conductive containers, Sensor length up to 4 m
The VEGACAP 27 is an adjustment-free, capacitive level sensor for liquids. Typical applications are overfill and dry run protection for adhesive as well as conductive liquids. The probe operates in liquids with a dielectric constant from 1.5.
Your benefit
- Long lifetime and low maintenance requirement through robust mechanical construction
- Minimum time and cost expenditure thanks to simple setup without medium
- Exact switching point even with strong buildup
