Variable speed drive ADV200-HC
ADV200-HC inverter series offers in a unique technology solution all the basic requirements demanded by the most modern industrial hoisting systems. The specific features, the robustness, the safety standards as well as the application flexibility makes ADV200 HC the ideal inverter to meet the operational needs of the most advanced systems.
A smarter Drive range with high performance and advanced controls, but ,at the same time simple in programming and installation.
MAIN FEATURES
- Field-oriented vector inverter
- Motor certifications from 0.75kW (1Hp) to 55kW (75 Hp)
- Power supply: 3 x 380…480Vac, 50/60Hz
- Integrated DC choke
- Integrated braking unit
- Integrated filter
- STO Safety board (optional)
- Certifications: CE. UL, cUL
FUNCTIONS
- Overload monitoring
- Brake control
- Joystick command management
- Low speed zoneAntisway control
- Limit switch management
- Hoist speed up and power up
- Anti impact
