Digital proportional servo valves Series LR
3/3-way directly operated servo valves for the flow (LRWD2),
pressure (LRPD2) and position (LRXD2) control
pressure (LRPD2) and position (LRXD2) control
Series LR digital proportional servo valves are direct driven 3/3-way valves with a patented rotating spool system with closed loop control circuit. The electronic board is integrated into the valve’s body ready to connect.
Series LR*D2 digital proportional servo valve has been designed to be as compact as possible in order to save space and to be mounted on a DIN-rail.
Thanks to this new digital version, the valve can be configurated through a USB connection according to different requirements.
