APF830 Series
The APF830 series is a positive displacement meter designed with a pair of tooth profile helical rotors, which displays totalizer with a mechanical pointer and provides 4-20 mA or pulse output. It has the advantages of no pulsation, low noise, high accuracy, high reliability, large measuring scope and strong environment adaptability.
APF830 series helical rotor flowmeter could be used in commercial measurement and engineering management control in petrochemical, metallurgical, electronics and other industries.
Features
- Pipe size : 25-300 mm (1″-12″)
- Fluid viscosity up to 20,000 cP
- High measurement accuracy, wide flow range and good repeatability
- Helical rotors rotate evenly, with little vibration and long lifetime
- Insensitive to viscosity variations in the measured liquid
- 6 Digit totalizer + 2 digit pointer
- High accuracy +/-0.5% of reading (or +/-0.2% of reading)
- 4-20 mA or pulse output
Specification
| Size | : | 25, 40, 50, 80, 100, 150, 200, 250, 300 mm |
| Measuring Range | : | 0.5-950 m3/hr |
| Accuracy | : | +/-0.5% of reading (Standard) |
| : | +/-0.2% of reading (Option) | |
| Repeatability | : | +/-0.1% of reading (Standard) |
| : | +/-0.07% of reading (Option) | |
| Material | ||
| Body & Cover & Flange | : | Cast Steel / S.S. 304 / S.S. 316 |
| Helical Rotor | : | Cast Iron / S.S. 304 / S.S. 316 |
| O-Rings | : | Viton |
| Shaft Sleeve | : | Ball / Ceramic Bearing |
| Register Housing | : | Aluminum Alloy |
| Max. Viscosity | : | 0.3-400 cP (Standard) |
| : | 400-2000 cP (Option) | |
| Operating Temp. | : | -10~120 °C (-10~80 °C with Output) |
| : | -10~120 °C with Output (Option) | |
| : | -10~250 °C (Option) | |
| Ambient Temperature | : | -25~60 °C |
| Max. Pressure | ||
| : | 63 kgf/cm2 (≤DN100) | |
| : | 25 kgf/cm2 (≥DN150) | |
| Painting | ||
| Body, Register | : | Red lead + Alia Blue |
| Housing | : | Red lead + Alia Blue |
| Process Connection | : | Flange |
| Flange Type | : | JIS 10K / JIS 20K / JIS 40K |
| : | ANSI 150# / ANSI 300# / ANSI 600# | |
| : | DIN PN10 / PN16 / PN25 / PN40 | |
| Mechanical Register | ||
| Totalizer (Non-Reset) | : | 6 Digit + 2 Digit Pointer |
| Totalizer (Resettable) | ||
| Upper Counter | : | 6 Digit + 2 Digit Pointer (Non-Resettable) |
| Lower Counter | : | 4 Digit + 2 Digit Pointer (Resettable) |
| Resolution | : | 0.1 Liter (25 mm) |
| : | 1 Liter (40-80 mm) | |
| : | 10 Liter (100-300 mm) | |
| Current Output | : | 4-20 mA (2-Wire) |
| Load | : | Rohm=(VDC-9) * 50 |
| Pulse Output | : | Open Collector (3-Wire, Unscaled Pulse) |
| Rating | : | 11-26 VDC, 50 mA Max. |
| Cable Entry | : | M20 (Standard) / 1/2″ NPTF (Option) |
| Protection Class | : | IP65 |
| : | Intrinsically Safe, Eex ia IIC T6 | |
| : | Explosion Proof, Ex d IIB T6 | |
| Optional | : | Heating Jacket (Hot oil or Steam) |
| : | Strainers, T-Type or Y-Type | |
| : | Strainer with Air Eliminator, Flange End |
RELATED PRODUCTS
AMC3200 Series
The ALIAMAG AMC3200 Series converter is a microprocessor-based intelligent transmitter that can be paired with any of the Alia AMF series sensors. The unit features multiple display parameters including flow rate, flow total, diagnostics, programming and troubleshooting. It is equipped with Bluetooth, HART and MODBUS communication functions.
AMF601 Series
The AMF601 Series is a sanitary-type electromagnetic flowmeter ideal for conductive liquids. It comes in sizes from 10-80 mm.
The AMF601 is widely used for drink water, milk, food & beverage juice and many other industrial fluids.
AMF601 Series electromagnetic flowmeter can be used in compact or remote model with AMC Series converter of electromagnetic flowmeter.
ATF3500 Series
